How to Identify Your Shower Valve Old Shower Valve Identification

How to Identify the Correct Shower Faucet and Cartridge Type

Identifying the Brand/Manufacturer of Your Shower Faucet

Faucets were standardized and each has the same internal components but have an entirely different style and design on the exterior. The replacement parts were bought from various suppliers and are therefore a quick repair. Nowadays, all manufacturers have their own specifications and specifications for parts.

There is now a variance with regards to stems (cartridges) and valves and splines. This is why you’ll need to learn which model of the faucet before you are able to repair it. Knowing the model of your faucet will make it simpler to take apart and repair. Start this process byfollowing:

1. You are looking for the name.
2. Identification of a faucet’s cartridge (chart).

Shower Faucet Type and Brand Identification

You can tell the faucet’s manufacturer when you look for a marking which indicates the source of it. It could be engraved, printed or laser-etched. The most popular brands are listed in the following table.

Read More : Can You Shower With A Gold Chain

What Kind of Shower Faucet Do I Have?

If you can’t find any indications in the tap, then you’ll need to begin disassembling it. Begin by removing the handle. It is possible to determine your length of the cartridge (stem) longitude of the tap or turn in the direction of the number of lines.

How to Take Apart a Shower Faucet

Step 1

The first step is to turn off water flow. This is done by finding the valves that cut off water (there will be two valves, one that is for hot water and one that is for cold). If you’re cleaning the shower, you’ll need to find the water mains valve to the building, which is on the outside of the house or the building.

Step 2

If you want to remove the handle to remove the handle, it is possible to do so with an appropriate screwdriver (Allen wrenches are suitable). The kind of screwdriver you require will depend on the kind of handle you want to remove:

• If you’re working with an uni-lever handle, then you’ll need to find one small set-crew within the handle, and then utilize the Allen wrench.
• If you’re working with a crystal handle it will probably have an aluminum cover that you can remove with an flat-head screwdriver. This will allow you to remove the stem using an Phillips screwdriver.
• If you’re working with an appliance that has two handles, take off the plastic cap with the decorative design (pry off the cap using the help of a Phillips screwdriver).

Step 3

After the screws have been removed after which you can pull the handle and stem apart. They typically come out of the handle from the handle. It is possible to move the stem before you take it off to completely remove it.

Moen Disassembly and Installation Instructions

Figure Out Where Your Faucet Is Leaking or Broken

Now is the time to identify the issue. If you’re experiencing an issue of leaks, you’ll likely observe that the rubber O-rings and washers are worn off (often due to aging). Replacement washers for rubber are inexpensive and simple to repair. You can bring your parts to the hardware store in your area (plumbing shops are great too). They’ll be able identify the faucet’s type and what part is failing. They can also assist to replace the part.

How to Identify the Cartridge Brand

You could reduce costs by finding out the cartridge’s brand. This can be done using the measurement of length of the cartridge and number of Splines. Once you have the information you need, you can examine them against an example. Take a look at this Interline brand cart identification chart PDF.

How to Use a Faucet (Valve/Stem) Cartridge Identification Chart

1. Make use of a ruler or caliper and take a measurement of the cartridge. Measure from the bottom to the top (from seat to the splines).
2. Be aware of the length of the cartridge (Lengths vary from 1 to 12).
3. Then, determine the broach pattern by using Broach charts (see the B-5 page).
4. Find the length of your stem’s the tier (as indicated on the left and right of every page).
5. Find the pattern for the broach that matches (alongside the photos of the cartridge). Check that it’s correct.
6. Next, you’ll make note of the parts numbers you’ll require.

Additional Tips for Repairing Shower Faucets

• Be aware of warranties: Keep all paperwork and documents regarding your faucet’s type and model. If it’s covered by warranty, you might be eligible for free replacement parts by contacting the manufacturer.
• Find out the sources for your brand: Brands like Pfister don’t offer parts in local hardware stores. Do look on Amazon for the same reason, however, since many parts are available on this site and shipping times can be within three days.
• Note what parts can be interchanged:Keep in mind that some O-rings, rubber seats and springs might not interchangeable. They may look alike to different brands, however they might not be identical. Delta valve seats for instance are identical to Pfister’s designs however the diameters are different , which can cause leaks and other issues.
